Co-Caring Housing

Location: Melrose, Bronx

Instructor: Benjamin Cadena

In Collaboration With: Maxwell Chen

GSAPP Fall 2019

Model Photo_website.jpg
1’ = 1/16” Scale Model

1’ = 1/16” Scale Model

The major concerns of the neighborhood Melrose, Bronx are drivers for this housing project: high population of single parenthood and health and wellness issues.

This housing project, the “Co-Caring” community, seeks to distribute multiple tasks and roles to share burdens and to alleviate the pressure of raising children with limited physical, emotional, and financial means under a single parenthood.

The common spaces not only include communal kitchens but also farming spaces that promotes healthier life. The idea is also reflected with the proposal of “Food and Nutrition Museum” on the ground level, providing green spaces, marketplace, and an educational facility for the public. The process of learning, growing, and making food intends to foster a collaborative and caring community.

physical - tile_Page_1.jpg
social tile_Page_2.jpg
physical - tile_Page_2.jpg

UNIT LIFE


A PICTURE OF WHAT IT’S LIKE TO LIVE IN THIS “CO-CARING” COMMUNITY:

A single mother just finished her night shift in the morning. As she arrived, her two kids woke up from the children’s dorm and got ready for school. The mother was in time for the community cooking workshop provided by the Food and Nutrition Museum. She is a new member of the community and is learning to cook healthy for the kids. The ingredients she used were grown in the urban farm in the community. After the workshop, she went back to bed to prepare for another shift. As her kids came back from school, the family were able to enjoy some family time in the market. The mother then left the kids with the parents on duty, a single dad with three kids and a single mom with one kid. The parents on duty picked up ingredients from the market and farm-shelves and cooked dinner in the common kitchen for a few kids and made sure they’ve done their homework. The kids went back to the dorm for another night before the weekend comes.

children dorm.jpg
demonstration kitchen sml.jpg
urban farming sml.jpg
market sml.jpg
Collage - Building Life sml.jpg
Collage - Unit Life sml.jpg

BUILDING LIFE

U-SHAPE LAYOUT TO CREATE MORE COMMUNAL SPACE

U-SHAPE LAYOUT TO CREATE MORE COMMUNAL SPACE

CLUSTER PLAN

CLUSTER PLAN

LIFE IN THE COMMUNAL SPACE

LIFE IN THE COMMUNAL SPACE

POROSITY ENHANCES ACCESSIBILITY

POROSITY ENHANCES ACCESSIBILITY

SPACE BETWEEN PUBLIC SPACE AND PRIVATE SPAE

SPACE BETWEEN PUBLIC SPACE AND PRIVATE SPAE

WINDOWS FACING COMMUNAL SPACE INCREASE VISIBILITY

WINDOWS FACING COMMUNAL SPACE INCREASE VISIBILITY

Model Photo8.png
Model Photo7.png
Model Photo6.png
TYPICAL PLAN

TYPICAL PLAN

URBAN LIFE


In the residence above, special amenities, in addition to the basic laundry and lounge, including urban farming spaces, daycare center, and playgrounds are located on the roof level of the four buildings connected by a sky bridge. They help increase the convenience of residents while educating them to live a healthier life.

ground floor plan2nd floor.jpg
ground floor plansitemap3300.jpg
Collage - Urban Life.jpg
